API610 Horizontal Centrifugal Multistage Steam Boiler Feed Hot Water Circulation Supply Pump

Basic Info.

Model NO.	BB4
Max.Head	>150m
Max.Capacity	>400 L/min
Driving Type	Electric
Material	as Customer Need
Structure	Multistage Pump
Assembly	Liquid Pumps
Power	Electric
Start Up	Electric Pump
Type	Multistage Pump
Application	Clarified Water Pump
Industry	Hot Water Pump
Media	Hot Water
Performance	Wear Pump
Theory	Centrifugal Pump
Medium T	Less Than 400c
Capacity	32~620m3/H
Head	550-4500m
Feature	ISO2858-1975
MOQ	1 Set
Delivery Time	According to Your Quality
Original	China Pump
Pump Features	Double Ends Mechanical Seal
Use in	Wastewater Treatment Systems
Other Details	Pls Check in Follow Data
Transport Package	Export Wooden Case
Specification	As details
Trademark	Tailide
Origin	Shenyang, China
HS Code	8413810090
Production Capacity	50000 Set/ Year

Packaging & Delivery

Package Size3000.00cm * 1200.00cm * 1300.00cm Package Gross Weight3000.000kg

Product Description

Multistage Water Pump BB4 BB5
BB4 is a centrifugal pump of horizontal, single suction, multistage and sectional structure. It owns the features of high efficiency, wide performance range, smooth operation, low noise, easy maintenance...Was designed to pump clean water or fluids have close characters of water. Also, by changing pump wetted parts, it is able to pump fluids like hot water, oil, corrosive fluids and fluids particles.

Parameters Range:

Application:

BB4 Feed Water Pump is multi-stage sectional centrifugal pump for medium pressure boiler water supply, also can be used for conveying similar liquid medium;

Structure:

1. The pump set mainly consists of bearing housing, inlet and out section, middle section, guide vanes.
2. The pump inlet is horizontal and outlet is vertical; The balance hose on the inlet is connected back to the water inlet side.
3. Between bearings structure. The rotary part consists of shaft, impellers and a balance disk.
4. The gaps between pump inlet section, middle section and outlet section are smeared by molybdenum disulfide compound calcium-based lubricating grease as the sealings. The gaps of rotary part and static part are sealed seal rings, guide vane sleeve and packing.
5. Standard shaft sealing is packing, can be customized as mechanical seal.

Main parts:
1. Suction stage 2. Diffuser 3. Middle stage 4. Discharge stage 5. First stage impeller 6. Impeller 7. Balancing Disc 8. Balance plate 9. Cover 10. Packing 11. Balance sleeve 12. Packing gland 13. Oring 14. Bearing 15. First stage sealing ring 16. Seal ring 17. Diffuser sleeve 18. Shaft 19. Shaft sleeve

Parts feature : Mech Seal:
Packing seal or Mechanical seal, if need cooling water. Seal plan: P11, P23, P32, P11+61, P11+53A, P11+53B. Mech seal factory is colossus.John crane..

Oil station:
If need use oil station, selected according to your technical parameter ..brand is china.

Bearing and balancing device:
All brand bearing. Pump rotor pump shaft at both ends of the Rolling bearing support, dilute oil lubrication, water cooling. The axial thrust of the rotor is balanced By the balance disc, and the equilibrium return water is returned to the suction section of the pump.

Transmission:
Feed Water Pump through the elastic coupling (or diaphragm coupling) and drive (motor, turbine, diesel engine etc. ) connected, Clockwise rotation from The drive end to the pump.

Motor:
China brand motor... Or others brand also can provide..

GA Drawing sample (BB4-850-55*8)

Material:
We will select material according to your technical sheet ( S-5,S-6,C-6,A-8...)

More Products picture:

WHY CHOSE FOR US?

1. According customer technical parameter, we will select suitable model , provide all technical document : GA drawing , C.S drawing .
curve . data sheet .2 years spare parts list .
2. OEM services according to clients' engineering drawings, samples. Products can be marked and labelled with clients' nameplates,
part numbers and other labels.
3. After-sales services provided, including pump installation, operation and maintenance instructions, centrifugal pumps repair and replacement.
4. We can provide ISO9001 ,ISO14001,BV ,CE certificate ...
5. Pump pass through TUV testing .
5. 18 MONTHS Warranty

Certificate we have


For more details (BB4), pls contact with us!
If need Double casing BB5 pump more details

Flow rate	Q=20~540m3/h
Total head:	H=16~1500m
Speed:	N=1450rpm/2950rpm
S. G.: Γ	≤1.15
Medium Temperature	T≤210ºC
Pump diameter	80, 100, 125, 150, 200, 250mm ( or other can OEM)
